 Rika Sensor is a weather sensor manufacturer and environmental monitoring solution provider with 10+ years of industry experience.

Rika top rated wind speed instrument industry for wind spped monitoring 1
Rika top rated wind speed instrument industry for wind spped monitoring 1

Rika top rated wind speed instrument industry for wind spped monitoring

Payment:
T/T, L/C or Paypal
OEM/ODM:
Available
MOQ:
2PCS
Model:
RK120-01C
Lead Time:
5-7 days
Certification:
CE-EMC, CE-LVD, RoHS, ISO9001
Inquiry
Enterprise Strength
  • Rika Sensors owns high-quality products and practical marketing strategies. Besides, we also provide sincere and excellent services and create brilliance with our customers.

PRODUCT DESCRIPTION

Rika top rated wind speed instrument industry for wind spped monitoring 2

RK120-01C Combined Wind Speed & Direction Sensor is assembled with aluminum alloy precision machined parts, which has high strength and convenient installation.The wind speed part adopts the traditional three-wind cup structure, the wind cup is made of carbon fiber material, the starting performance is good, the measuring range is large, the linearity is good, stable and reliable.The wind direction part adopts low inertia wind direction to respond to the wind direction. When the wind direction changes, the tail wheel drives the angle sensor to sense the azimuth change, thereby generating a change of electrical signal output, good linearity, high precision, and no blind zone.

Rika top rated wind speed instrument industry for wind spped monitoring 3

SPECIFICATIONS


Item

Technical Specification


Wind speed

Wind direction

Range

0-45m/s(current or voltage ouput);


0-70m/s(pulse,RS485,RS232 output)

0-360°

Resolution

0.1m/s

Accuracy

±(0.3+0.03V)m/s ,V is current wind speed

≤±3°

Acquisition Cycle

3s

Starting wind speed

0.5m/s

Limited wind speed

75m/s

Supply

5V(only for digital output),12-24VDC

Output Signal

RS485,4-20mA,0-5V,RS232,pulse(NPN,only for wind speed)

Operating Temperature

-40℃-+70℃

Ingress Protection

IP65

Main material

Aluminum alloy and carbon fiber

                 Cups:PA, reinforced with carbon fibre, black

              Vane:PA, reinforced with fiberglass, white


Storage10-60℃@20%-90%RH
Cable lengthDefault 2.5m,other length is optional
Installation bracketattached
Weight(unpacked)700g




DIMENSION & MOUNTING

Unit:mm
Unit:mm

Unit:mm

PRODUCT DETAILS

Rika top rated wind speed instrument industry for wind spped monitoring 12

Rika top rated wind speed instrument industry for wind spped monitoring 13Product Principle & Output

Rika top rated wind speed instrument industry for wind spped monitoring 14

Rika top rated wind speed instrument industry for wind spped monitoring 15 Product Material

PRODUCT MOUNTING

Rika top rated wind speed instrument industry for wind spped monitoring 16

PRODUCT APPLICATION
