RKL-05 Radar Velocity Sensor
RKL-05 Radar flowmeter
RKL-05 Radar flowmeter
RKL-05
RKL-05 Radar flowmeter
RKL-05 Radar flowmeter
RKL-05 Radar flowmeter
RKL-05 Radar Velocity Sensor
RKL-05 Radar flowmeter
RKL-05 Radar flowmeter
RKL-05
RKL-05 Radar flowmeter
RKL-05 Radar flowmeter
RKL-05 Radar flowmeter

RKL-05 Radar velocity sensor

    oops...!

    no product data.

    Go to homepage
    RKL-05 Radar velocity specification v5
    RKL-05 Radar velocity specification v5
    PDF Download

    PRODUCT DESCRIPTION

    The RKL-05 Radar Velocity Sensor is a cutting-edge, non-contact instrument engineered for precise surface water velocity measurement in natural and artificial channels. Utilizing 24GHz frequency-modulated continuous wave (FMCW) technology, it delivers reliable, real-time data without disrupting water flow. Designed for 24/7 unattended operation, it excels in hydrology, flood forecasting, drainage management, and environmental monitoring, combining ruggedness with low power consumption for deployment in remote or harsh environments.


    Why Choose the RKL-05?​​

    • ​​Zero Maintenance​​: IP68 housing and solid-state electronics eliminate field servicing.
    • Adaptability​​: Flat microstrip array antenna (14°×32° beam) captures data in turbulent or shallow flows.
    • ​​Data Integrity​​: Automatic angle correction and noise filtering ensure consistent accuracy.
    • ​​Scalability​​: Customizable cable lengths (default 5 m) and voltage input (7–28 VDC).


    RKL-05 Radar velocity sensor 8
    RKL-05 Radar velocity sensor 9
    Excellent stability
    RKL-05 Radar velocity sensor 10
    Fast response
    RKL-05 Radar velocity sensor 11
    24/7 online automatic monitoring
    RKL-05 Radar velocity sensor 12
    High accuracy
    RKL-05 Radar velocity sensor 13
    Anti-corrosion material optional
    RKL-05 Radar velocity sensor 14
    Strong resistance to interference

    SPECIFICATIONS

    Item

    Technical Specification

    Frequency

    24.000~24.250GHz

    Range

    0.1~20 m/s(It has to do with the flow pattern)

    Accuracy

    ±1%FS

    Resolution

    0.01m/s

    Effective distance

    0.5-30m

    Measurement time

    3~240s

    Supply

    7~28VDC(suggested use 12v)

    Power consumption

    Working current:120mA@12V;
    Standby current:1mA@12V

    Output

    RS485(MODBUS-RTU)

    Automatic angle correction

    30-60°

    Antenna style

    Flat microstrip array antenna,14°×32°

    Working temperature

    -40~+85℃

    Protection grade

    IP68

    Product size

    110×110×43mm

    Weight

    1.1kg

    Cable length

    5m default,customizable

    Dimension

    Unit:mm
    Dimension diagram of RKL-05 radar flowmeter

    Mounting

    RKL-05 product installation diagram
    It is recommended that the radar beam should be directed towards the water flow,as shown in the figure.The radar tilt angle(the residual angle between the radar beam and the horizontal plane)should be withinthe range of 30 degrees to 45 degrees,and 30 degrees is recommended.

    PRODUCT APPLICATION

    RKL-05 Radar velocity sensor 17
    Biodegradation
    RKL-05 Radar velocity sensor 18
    Agricultural Irrigation
    RKL-05 Radar velocity sensor 19
    Chemical
    RKL-05 Radar velocity sensor 20
    Reservoir
    RKL-05 Radar velocity sensor 21
    River
    RKL-05 Radar velocity sensor 22
    Water Treatment
    RKL-05 Radar velocity sensor 23
    Well
    RKL-05 Radar velocity sensor 24
    Urban Sewage
