best weather station radiation shield solution provider for relative humidity measurement

Product Comparison

environmental sensor is in line with the stringent quality standards. The price is more favorable than other products in the industry and the cost performance is relatively high.Compared with other same kind of products in the market, Rika Sensors's environmental sensor is equipped with the following outstanding advantages.

Product Details

Rika Sensors's weather sensors has excellent performances, which are reflected in the following details.weather sensors, manufactured based on high-quality materials and advanced technology, has reasonable structure, excellent performance, stable quality, and long-lasting durability. It is a reliable product which is widely recognized in the market.

PRODUCT DESCRIPTION

The Multi-Plate Radiation Shield protects temperature,relative humidity or barometric pressure sensors from error-producing solar radiation and precipitation. This shield relies on a combination of plate geometry, material and natural ventilation to provide effective shielding. The radiation shield reflect sunlight from any direction, prevent sun direct radiation and reflection on the ground to the sensor radiation, to protect the instrument from the effects of strong winds, rain, snow, etc.Freely through the air, making instrument work in ventilated environment, to ensure the accuracy of measured data.Products with high reflectivity and low thermal conductivity, resistance to ultraviolet ray function, can be used in extreme weather conditions.

best weather station radiation shield solution provider for relative humidity measurement-1

best weather station radiation shield solution provider for relative humidity measurement-2

Compact size for easy use

best weather station radiation shield solution provider for relative humidity measurement-3

Good air circulation around shield

best weather station radiation shield solution provider for relative humidity measurement-4

Excellent stability

best weather station radiation shield solution provider for relative humidity measurement-5

Simple operation screen

SPECIFICATIONS

Item	Specifications
Number of plates	4 -20 plates optional,typ.:11,14,19
Color	White
Material	Anti-radiation ABS engineering plastics & Stainless steel screw
Operating temperature	-40℃-+75℃
Dimension	Inner diameter:62mm,Outer diameter:140mm/180mm Height:180mm(11 plates),220mm(14 plates),280mm(19 plates)
Optional accessories	Metal bracket(304SS),Embrace hoop screw(inner diameter:60mm,304SS)

BRACKET DIMENSION & WATERPROOF GLANDS SPECIFICATIONS

All 304 stainless steel material （Unit:mm）

best weather station radiation shield solution provider for relative humidity measurement-6

best weather station radiation shield solution provider for relative humidity measurement-7

Waterproof Glands Specifications

DIMENSION

best weather station radiation shield solution provider for relative humidity measurement-8

Plates	Inner space(mm)	D1(mm)	H1(mm)	H2(mm)
4	ø62*45	140	51	approx.55
5	ø62*57	140	64	approx.55
6	ø62*70	140	76	approx.55
7	ø62*82	140	89	approx.55
8	ø62*95	140	101	approx.55
9	ø62*107	140	114	approx.55
10	ø62*120	140	126	approx.55
11	ø62*132	140	139	approx.55
12	ø62*145	140	151	approx.55
13	ø62*157	140	164	approx.55
14	ø62*170	140	176	approx.55
15	ø62*182	140	189	approx.55
16	ø62*195	140	201	approx.55
17	ø62*207	140	214	approx.55
18	ø62*220	140	226	approx.55
19	ø62*232	140	239	approx.55
20	ø62*245	140	251	approx.55

ADAPTER WATERPROOF GLANDS

PG Glands
Model	Cable/Sensor Diameter(mm)
PG7	3-6.5
PG9	4-8
PG11	5-10
PG13.5	6-12
PG16	10-13
PG19	12-15
PG21	13-18
PG25	16-21
PG29	18-25
PG36	22-32

best weather station radiation shield solution provider for relative humidity measurement-9

PRODUCT DETAILS

best weather station radiation shield solution provider for relative humidity measurement-10

best weather station radiation shield solution provider for relative humidity measurement-11 Enhanced UV resistance plastic

best weather station radiation shield solution provider for relative humidity measurement-12

best weather station radiation shield solution provider for relative humidity measurement-13 Plates quantity

best weather station radiation shield solution provider for relative humidity measurement-14

best weather station radiation shield solution provider for relative humidity measurement-15 Support & Mounting

best weather station radiation shield solution provider for relative humidity measurement-16

best weather station radiation shield solution provider for relative humidity measurement-17 Connectors for sensors

PRODUCT APPLICATION

best weather station radiation shield solution provider for relative humidity measurement-18

Agriculture Weather Station

best weather station radiation shield solution provider for relative humidity measurement-19

Automatic weather station

best weather station radiation shield solution provider for relative humidity measurement-20

PV Station

best weather station radiation shield solution provider for relative humidity measurement-21

Scenic Spot

best weather station radiation shield solution provider for relative humidity measurement-22

Schoolyard Weather Station

Weather Station

r******v

The quality management of Rika Sensors radiation shield is attached 100% importance. From the selection of the raw materials to the finished products, each step of inspection is strictly conducted and followed to meet the regulation of gifts and crafts. This product is characterized by its drop-in replacement

i******k

Rika Sensors radiation protective shields is designed to complying the energy saving philosophy. It is created to maximize the use of solar light so as to reduce the use of non-renewable resources. This product features a super long cycle lifespan

s******w

The design of Rika Sensors weather station radiation shield is a consequence of many combined parameters. Geometry, materials, surface area design, and air velocity are all seriously considered in enhancing the performance of the product. Its efficiency is unparalleled, especially under high-stress situations

m******b

Rika Sensors solar radiation shield is created by the R&D team who spent lots of time and efforts analyzing its thermal performance and the most appropriate contact area for the product and the devices. This product can last for five years or more

b******w

Rika Sensors radiation shield is professionally designed. It is carried out by our robust team who use advanced tools to design medical products with complex mechanical and electromechanical systems. It contains relatively low levels of toxic heavy metals

x******n

The quality of this product can be guaranteed with the support of the QC team. It can charge and discharge at a high rate
