RK400-14 Customized Laser Snow Depth Sensor
PRODUCT DESCRIPTION
RK400-14 has a large measuring range and high accuracy,with a maximum accuracy of 1mm.It also hassuper anti-interference ability and is widely used in various industrial control such as steel industry,metallurgical industry,automobile industry,printing industry,food industry,etc.,and various field monitoringand inspection sites.The principle of the laser snow depth sensor is the optical triangulation method,and thesemiconductor laser is focused on the measured object by the lens.The reflected light is collected by the lensand projected onto the CMOS array;the signal processor calculates the position of the light spot on the arraythrough the trigonometric function to obtain the distance to the object.
SPECIFICATIONS
Item | Specification |
Range① | 0-15m |
Laser characteristics | Red laser diode |
Wavelength | 620nm~650nm |
Laser class | Level 2 |
Spot type | Point |
Spot size | Spot light spot 5mm@10m Line spot 3mm*150mm@10m |
Protection level | IP68 |
Resolution | 1mm |
Accuracy | ±1cm |
Pow er consumption | <0.8W (w ithout heating) |
Supply | 12VDC |
Output | SDI-12 |
| Operatingtemperature | -40-+50℃ |
Heating | Automatic , it can be turned on or off through commands |
Installation angle | Automatically calculate 0 °and installation angle , <30 °is allow ed |
Mounting | Include accessories of mounting to mast vertical of 4 inches of diameter |
Main material | White steel coated or sprayed |
Weight(unpacked) | 2.5kg |
①The sensor has a 10cm measurement blind spot
