PRODUCT DESCRIPTION

RK500-01 Soil/Liquid Temperature Sensor is used to measure the temperature of the soil or liquid medium, applied to the automatic meteorological station, soil temperature testing, pond or reservoir water temperature detection and other fields.The products can be used into the water or buried in the soil.Sensor with precision thermal resistance as a sensing component, built-in signal sampling and amplification, zero drift and temperature compensation function, has the characteristics of high measuring precision and good stability.

best soil salinity sensor solution provider for soil monitoring-1

best soil salinity sensor solution provider for soil monitoring-2

SPECIFICATIONS

Item	Technical Specification

Range	-20-+50℃,-50-+100℃
Supply	5VDC,12-24VDC
Accuracy	±0.5℃
Response Time	<1s
Output Signal	PT100/PT1000 class A (3-wires),4-20mA,0-5V,RS485
Operating Temperature	-50℃-+80℃
Ingress Protection(probe)	IP68
Storage	10-60℃@20%-90%RH
Size	4-20mA,0-5V,RS485: Probe:Ø19 ×119 mm,Transmitting module:Ø27*120mm PT100: Probe:Ø6 ×50mm
Probe weight(unpacked)	145g
Housing material	304 stainless steel

If you select 4-20mA,0-5V,RS485 output,need add transmitting module.

DIMENSION

Unit:mm

best soil salinity sensor solution provider for soil monitoring-8

PRODUCT DETAILS

best soil salinity sensor solution provider for soil monitoring-9

best soil salinity sensor solution provider for soil monitoring-10 Product Principle & Material

best soil salinity sensor solution provider for soil monitoring-11

best soil salinity sensor solution provider for soil monitoring-12 Muitiple Output Optional

best soil salinity sensor solution provider for soil monitoring-13

best soil salinity sensor solution provider for soil monitoring-14 IP67 Waterproof

PRODUCT APPLICATION

best soil salinity sensor solution provider for soil monitoring-15

q******g

The design of Rika Sensors soil salinity sensor involves several stages. They are trend studies, fabric and accessory research, sample making, etc. Adopting nano-waterproof technology, it can be used outdoors

d******l

Rika Sensors soil salinity sensor is required to undergo a series of tests. The tests include the insulation properties of materials, the integration of the circuit board, the shockproof performance of housing. The product is in strict accordance with the requirements of CE, CCC, and CQC

h******k

Rika Sensors soil salinity sensor 's design takes into account the use of color. This is decided by fashion professionals who understand color psychology and chemistry. The product is in strict accordance with the requirements of CE, CCC, and CQC

t******k

Rika Sensors soil salinity sensor is designed using a variety of techniques. Its design is with the add of the CAD system, CNC machine tool processing, hydraulic pneumatic transmission, plc function design, etc. It has wide applications, including home, garden, yard, farm, community road, industrial zone, and school

c******j

Rika Sensors best soil moisture meter is carefully manufactured. The production process includes cutting, sewing and finishing. Being divided into many fine operations, it is necessary to produce the product. It has an automatic charge and discharge management function

h******h

This best soil moisture meter is best soil moisture meter and practical for best soil moisture meter. The energy conversion process of this product is noise- and pollution-free
