Rika Sensor is a weather sensor manufacturer and environmental monitoring solution provider with 10+ years of industry experience.
Rika best data logger industry for data acquisition systems
Payment:
T/T, L/C or Paypal
MOQ:
1PCS
Model:
RK600-07
Lead Time:
5-7 days
Certification:
CE-EMC, CE-LVD, RoHS, ISO9001
Item | Technical Specification | ||
Display | 3.5” TFT true color LCD display, 320 * 240 resolution, high-definition LED back-light, three side close to zero point of view | ||
Input channels | 1-18 optional(signal type can be configured) | ||
Input signal | Current:4-20mA,0-10mA,0-20mA Voltage:0-5V,0-10V,1-5V Thermocouple:B,E,J,K,S,T,R,N Thermal resistance:Cu50,PT100 Other signals can be customized | ||
Accuracy | 0.2%FS | ||
Internal storage capacity | 48M | ||
External storage | U-disk(attached) | ||
Supply | AC220V,DC24V | ||
Power consumption | 20VA(max.) | ||
Operating temperature | -10-+55℃@10-85%RH | ||
Storage condition | -20-+60℃@5-95%RH | ||
Communication mode | RS485(MODBUS-RTU),RS232(add external module) | ||
Output capability | 3.6W(24V@150mA) | ||
| Sample Period | 1s | ||
| Power-drop protection | Data stored in the internal flash, historical data and configuration parameters will not be lost when power supply drop | ||
| Alarm output | Max.4 channels relay NO,250V/2A | ||
| Dimension | 96*96*100mm(hole size:92*92mm) | ||
| Installation of panel thickness | 1.5-6mm | ||
| Weight(unpacked) | 370g | ||
