PRODUCT DESCRIPTION

The Multi-Plate Radiation Shield protects temperature,relative humidity or barometric pressure sensors from error-producing solar radiation and precipitation. This shield relies on a combination of plate geometry, material and natural ventilation to provide effective shielding. The radiation shield reflect sunlight from any direction, prevent sun direct radiation and reflection on the ground to the sensor radiation, to protect the instrument from the effects of strong winds, rain, snow, etc.Freely through the air, making instrument work in ventilated environment, to ensure the accuracy of measured data.Products with high reflectivity and low thermal conductivity, resistance to ultraviolet ray function, can be used in extreme weather conditions.

Rika Sensors solar irradiance sensor price manufacturer for relative humidity measurement 2

Excellent stability

Good air circulation around shield

Compact size for easy use

Simple operation screen

SPECIFICATIONS

Item	Specifications
Number of plates	19 plates
Color	Out surface:Light grey,inner surface:black
Material	PC & 304SS screw
Operating temperature	-40℃-+80℃
Sensor installation interface	Glands: M32*1.5(Suitable for 16-20 mm diameter probe)
Installation bracket	304SS bracket

Other plate can be customized

DIMENSION

Unit:mm

Rika Sensors solar irradiance sensor price manufacturer for relative humidity measurement 7

PRODUCT APPLICATION

Agriculture Weather Station

Weather Station

Schoolyard Weather Station

PV Station

Automatic weather station

Scenic Spot

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
