    RK500-17 Chlorophyll sensor specification v4
    RK500-17 Chlorophyll sensor specification v4
    PDF Download

    PRODUCT DESCRIPTION

    The RK500-17 Chlorophyll Sensor leverages advanced optical technology to deliver precise, real-time monitoring of chlorophyll concentrations in aquatic environments. Designed for long-term deployment with minimal maintenance, this integrated sensor features robust construction, high-efficiency power management, and exceptional stability—eliminating the need for frequent calibration. Ideal for continuous online use, it supports critical research and monitoring of algae, phytoplankton, and water quality across diverse settings, from freshwater ecosystems to marine applications.


    Why Choose the RK500-17?​​

    • Long-Term Reliability​​: Sturdy housing and sealed electronics ensure years of service in corrosive or high-pressure environments.
    • ​​Zero-Hassle Operation​​: Autonomous operation reduces fieldwork costs and training needs.
    • Ecosystem Insights​​: Enables data-driven decisions for sustainable water resource management.
    Chlorophyll sensor
    RK500-17 Chlorophyll sensor 9
    Fast response.
    RK500-17 Chlorophyll sensor 10
    Excellent stability.
    RK500-17 Chlorophyll sensor 11
    Widely used.
    RK500-17 Chlorophyll sensor 12
    High precision.
    RK500-17 Chlorophyll sensor 13
    High sensitivity.
    RK500-17 Chlorophyll sensor 14
    Simple operation.

    SPECIFICATIONS

    Item

    Specification

    Range

    0~500μg/L

    Accuracy

    ±3%FS

    Resolution

    0.1 μg/L

    Power

    7-28VDC

    Response time

    2s

    Power consumption

    <0.5W

    Output

    4-20mA&RS485(Modbus-RTU)

    Main material

    316L or ABS

    Pressure resistance

    <0.8MPa

    Protection class

    IP68

    Cable length

    5 m(default), customizable

    DIMENSION

    Unit:mm

    RK500-17 Chlorophyll sensor 15

    PRODUCT APPLICATION

    RK500-17 Chlorophyll sensor 16
    Agricultural Irrigation
    RK500-17 Chlorophyll sensor 17
    Chemical
    RK500-17 Chlorophyll sensor 18
    Urban Sewage
    RK500-17 Chlorophyll sensor 19
    Biodegradation
    RK500-17 Chlorophyll sensor 20
    River
    RK500-17 Chlorophyll sensor 21
    Reservoir
    RK500-17 Chlorophyll sensor 22
    Well
    RK500-17 Chlorophyll sensor 23
    Water Treatment

    CUSTOMER TESTIMONIALS

    RK500-17 Chlorophyll sensor 24
    RK500-17 Chlorophyll sensor 25

    CUSTOMER TESTIMONIALS

    RK500-17 Chlorophyll sensor 28
    ISO9001
    RK500-17 Chlorophyll sensor 29
    CE-Automatic Weather Station
    RK500-17 Chlorophyll sensor 30
    EMC-Soil Moisture, Temperature & EC Sensor
    RK500-17 Chlorophyll sensor 31
    TUV Certificate
